Product description

?What is Iron slag?crusher

Iron slag crusher is also known as roll crusher, roll crusher and roll breaker. Roller crusher is to use two sets of individual transmission rollers, relative rotation to produce the squeezing force and grinding shear force to crush materials. When the material enters the crushing chamber of the machine, the material is subjected to the meshing force of the rotating rollers, so that the material is forced to pass between the two rollers, and at the same time, the material is subjected to the squeezing and shearing force of the rollers, and the material starts to be crushed, and the small particles after being crushed will pass through the gap of the two rollers along the tangent line of the rotating rollers and be thrown out below the machine, and large particles over the gap will continue to be crushed and be discharged as small particles.

Roller crusher (roller crusher) can be used in mineral processing, chemical cement, refractory materials, abrasives, building materials and other industrial sectors, fine crushing of high. The roller crusher can be used in mineral processing, chemical cement, refractory materials, abrasive materials, building materials and other industrial sectors to finely crush high... Roller crusher (roller breaker) especially in the refractory materials and mining industry than the general crushing machinery. In recent years, it is also widely used in crushing iron slag.

Reasons for?choosing?us

1. Compared with hammer sand making machine, roller crusher does not need to replace wearing parts.

2. The finished product features pretty shape, well gradation, low over-crushing rate and high output.

3. Roller crusher is superior to hammer crusher and impact crusher, and the average service life ofitsroller sleeve is more than 2 years.

4. Roller skin contains high content of chromium, manganese and other rare metal materials. Adjustable discharge size.

Machine-testing Video

It is suitable for crushing sticky stone material into medium size. Roller crusher utilizes two rollers rotating in opposite direction to crush the material, which consists of motor, bracket, fixed rollers, movable rollers and springs.

Iron Slag crusher is to use two sets of individually driven rollers to crush materials by squeezing and grinding shear force generated by relative rotation. The material falls into between the two rollers through the feeding port, and the finished products fall naturally after crushed by the roller extrusion. When encountering too hard or unbreakable materials, the rollers can automatically back off by the action of hydraulic cylinder or spring, so that the gap between the two rollers increases, and the hard or unbreakable materials fall naturally to ensure that the machine is not damaged, Two rollers rotating in opposite directions can be used to control the particle size of the product by adjusting the pressure of hydraulic cylinders or springs.

Rocks roller crusher working principle

The Iron Slag crusher operates through rollers. The Iron Slag, put into the machine through the inlet, are crushed by the squeezing between the rollers. The discharge size can be controlled by adjusting the gap between the two rollers. If the gap becomes larger, the discharged size becomes larger. While the gap becomes smaller by compressing spring, the discharge size also becomes smaller.

Product category

Roller crusher is divided into several kinds: Spring fine crushing sand making machine, cardan shaft drive roller crusher, hydraulic fine crushing sand making machine.You can choose the machine according to your budget and the facts.

Product Model

There are small, medium and large? roller crusher.

1. Small stone roller crusher: 250x250，400x250，400x400，610x400? Production capacity: 2-12 tph

2. Medium roller crusher: 750x500，800x600，800x800，1000x800? Production capacity: 20-50 tph

3. Large roller crusher: 1200x800，1200x1000，1500x800，1500x1000，1500x1200，1800x1200，2000x1000 or larger? Production capacity: 50-400 tph

HSM machines?features different configurations. The sales manager can recommend the proper product to the customers?according?to their facts.





// Start For Horizontal Slider

Sand Production Application

In sand production lines, the double-roll crusher functions as a sand-making machine, offering advantages such as no wear parts, low maintenance costs, adjustable sand particle size, high yield rate, and excellent sand particle shape. It is widely used in the sand-making industry.

Mineral Processing Crushing Applications

In the mineral processing industry, double-roll crushers or high-pressure roller mills are employed for fine crushing operations. Positioned upstream of ball mills, they can reduce 2-3 cm ore particles to less than 1 mm, significantly enhancing the operational efficiency of mineral processing ball mills and boosting overall production productivity.

The? double roller crusher performs crushing operations through rollers. The material enters between the rollers from the feed port and crushes the river pebbles through the extrusion action. There is a certain gap between the two rollers. The larger the gap between the two rollers, the larger the material output size. Under the action of the compression spring, the smaller the gap between the two rollers, the smaller the material output size. By changing the gap, the material output size can be controlled.

Technical parameters

•

•
•
•
